Smarter recognition. Smoother entry.
Purpose-built imaging and access-control capabilities for automated vehicle entry applications.
Dedicated ANPR Engine
Automatic number plate recognition supported by intelligent AI processing.
Dual illumination
Integrated IR illumination up to 60m and warm-light illumination up to 50m.
Motorised varifocal lens
Adjustable 2.8–12 mm lens for flexible camera positioning and setup.
4MP high-sensitivity sensor
1/1.8-inch CMOS imaging with up to 2688 × 1520 resolution and 130 dB WDR.
Opyn Multi compatible
Wiegand connectivity supports integration with AES Global Opyn Multi for vehicle entry management.
Built for outdoors
IP67-rated metal housing, IEEE 802.3at PoE and an operating range of −40°C to +60°C.
SMARTER VEHICLE ACCESS STARTS HERE.
Intelligent number plate recognition for seamless, secure vehicle entry. Designed to deliver reliable performance, day and night.
From vehicle approach to authorised entry.
The camera recognises a vehicle's number plate and can form part of an integrated access-control system. The diagram illustrates an authorised barrier-entry scenario.
Vehicle approaches
The ANPR camera captures and recognises the number plate.
Access system processes the recognition
Wiegand integration enables the camera to work with a compatible access-control setup, including Opyn Multi.
Barrier operates when authorised
The connected access-control equipment can allow entry for an authorised vehicle.
Illustrative access-control diagram from the supplied AES Global datasheet. Barrier/
controller configuration depends on the installation.
Designed For Real-World Conditions.
High-resolution capture, flexible optics and rugged construction in one network camera.
4MP
High-sensitivity image sensor
60 m
IR illumination distance
130 dB
Wide dynamic range
IP67
Weatherproof metal housing
